Deployment
Overboarding Chutes
Stern and side chutes engineered for safe cable overboarding.
Stern and side chutes engineered for safe cable overboarding.
Roller-mounted overboarding chutes that guide cable, umbilical or pipe from the lay tensioner over the vessel stern or side, respecting the product's minimum bend radius and providing smooth load transfer to the catenary.
Reference imagery showing typical overboarding chutes configurations and offshore deployment scenes.
Reference photos are general industry illustrations of equipment of this type, used here for indicative purposes. Project-specific design renderings are provided as part of the formal engineering submission.
Indicative configuration ranges. Final specification is project-dependent and confirmed during FEED.
| Parameter | Value |
|---|---|
| Chute Radius | 1.5 m – 6.0 m (per design) |
| Working Load | Up to 200 T residual tension |
| Roller Type | Polyurethane / coated steel |
| Roller Pitch | 200 – 400 mm |
| Configuration | Stern, side or moonpool |
| Adjustability | Tilt ± 15° |
| Cable / Pipe OD Range | Up to 1,200 mm |
| Material | Painted carbon steel / SS304 |
| Class | DNV / BV / LR |
| Foundation | Welded to deck, sea-fastened |
| Span | Up to 15 m |
| Mass | 12 – 60 t |
Submarine cable lay overboarding
Pipeline overboarding during S-lay operations
Umbilical and flexible deployment
Beach-pull and shore-end installations
